Description
Godox MoveLink M1 Wireless Microphone System Overview
The Godox Movelink M1 microphone is a great and easy-to-use device for many content creators, including vloggers, Youtubers, speakers, interviewers, and filmmakers. It is measured by 5*4*1.4cm and weighs 27 g, making it easy to use and portable for many users on the go. With its 2.4GHz wireless microphone system, this device can allow stable and excellent transmission without any interference when in use. In addition to these features, the Godox Movelink M1 has a small clip-back clip, allowing users to put on the hot shoe of the camera, clip to the camera strap, and anywhere.
Its a 1.2m lav mic that’s easy to clip onto your clothing. Due to its Mono and stereo, the Godox Movelink M1 can allow users to record at the same time. It also has 3.5mm TRS and TRRS cables, which are well-suited for smartphones, tablets, cameras, recorders, etc.
Key Features
- Easy to use and operate
- 2.4GHz wireless microphone system ensuring stable transmission and audio
- Great fit for many video creators including vloggers, YouTubers, speakers, interviewers, filmmaker
- Free to switch between mono/stereo mode, offering flexibility to users
- With a portable charge case, easy to charge the device
Specifications
|
Wireless Technology |
Digital 2.4 GHz |
|
Included Transmitters |
1 x Clip-On |
|
Diversity |
Frequency |
|
Max Operating Range |
164' / 50 m (Line of Sight) |
|
Receiver Type |
Camera-Mount / Beltpack / Portable |
|
Microphone Type |
Integrated |
|
Polar Pattern |
Omnidirectional |
|
Microphone Type |
Lavalier |
|
Polar Pattern |
Omnidirectional |
System
|
Wireless Technology |
Digital 2.4 GHz |
|
Included Transmitters |
1 x Clip-On |
|
Diversity |
Frequency |
|
RF Channel Scanning |
Auto-Scan |
|
Max Operating Range |
164' / 50 m (Line of Sight) |
|
Max Transmitters per Band |
8 |
|
Built-In Recorder |
No |
|
Timecode Support |
None |
|
Dynamic Range |
100 dBA |
|
Encryption |
None |
Receiver
|
Receiver Type |
Camera-Mount / Beltpack / Portable |
|
Mounting Options |
Belt Clip, Shoe-Mount (with Included Hardware) |
|
Number of Audio Channels |
2 |
|
Audio I/O |
1 x 1/8" / 3.5 mm TRS Female Unbalanced Line Output |
|
Gain Range |
-5 to +10 dB (1 dB Steps) |
|
Phantom Power Protection |
None |
|
Frequency Response |
50 Hz to 20 kHz |
|
Network I/O |
None |
|
Word Clock I/O |
None |
|
USB/Lightning Connectivity |
1 x USB-C (Bus Power, Charging) |
|
Power Requirements |
Battery or Bus Power (USB) |
|
Battery Type |
1 x Built-In Rechargeable |
|
Internal Battery Capacity |
300 mAh |
|
Battery Charging Time |
1.5 to 2 Hours |
|
Approx. Battery Life |
6 Hours (Lithium Rechargeable) |
|
Display & Indicators |
TFT (AF Level, Battery Status, Metering, Multifunction, Output Level, Recharging, Sync, Transmitter Battery Status) |
|
Operating Temperature |
14 to 122°F / -10 to 50°C |
|
Dimensions |
1.6 x 2 x 0.6" / 40 x 50 x 14 mm |
|
Weight |
1 oz / 27 g |
Transmitter
|
Transmitter Type |
Clip-On with Microphone |
|
RF Output Power |
Not Specified by Manufacturer |
|
Audio I/O |
1 x 1/8" / 3.5 mm TRS Female Input |
|
Pad |
None |
|
Muting |
Mute Switch |
|
Auto-Level Control |
No |
|
Signal Processing |
None |
|
Frequency Response |
50 Hz to 20 kHz |
|
Sync Method |
Proprietary |
|
Power Requirements |
Battery |
|
Battery Type |
1 x Built-In Rechargeable |
|
Internal Battery Capacity |
300 mAh |
|
Battery Charging Time |
1.5 to 2 Hours |
|
Approx. Battery Life |
6 Hours |
|
USB/Lightning I/O |
1 x USB-C (Bus Power, Charging) |
|
Display & Indicators |
1 x TFT (Audio Level, Battery Status, Mute, Sync) |
|
Operating Temperature |
14 to 122°F / -10 to 50°C |
|
Dimensions |
1.6 x 2 x 0.6" / 40 x 50 x 14 mm |
|
Weight |
1 oz / 27 g |
Microphone
|
Microphone Type |
Integrated |
|
Sound Field |
Mono |
|
Capsule |
Electret Condenser |
|
Polar Pattern |
Omnidirectional |
|
SNR |
70 dB |
|
Equivalent Noise Level |
21.8 dB A-Weighted |
|
Maximum SPL |
Omnidirectional: 100 dB SPL |
|
Sensitivity |
-32 dB |
|
Dynamic Range |
100 dB A-Weighted |
Microphone 2
|
Microphone Type |
Lavalier |
|
Sound Field |
Mono |
|
Polar Pattern |
Omnidirectional |
|
Outputs |
1 x 1/8" / 3.5 mm TRS Male Unbalanced |
|
Cable Length |
3.9' / 1.2 m |
Stable Transmission and up to 50-meter Working Distance
The 2.4GHz wireless microphone system -well above other wireless systems used by other microphone brands, uses frequency-hopping technology to minimize interference, offers decent recording range and sound, and is compatible with many devices. Thanks to its maximum recording distance of 50 meters, this microphone device can be well-suited for many outdoor activities.
Easy to Use and Carry Around
Measured by 5*4*1.4cm and weighing 27 g, the Godox Movelink makes it easy to use and carry. This lightweight design is a fit for many users on the go. With its built-in Omni-directional condenser mic, it is easy for users to record sound. This unit is equipped with a 1.2m lav mic that can be clipped into your clothing easily and 3.5mm TRS and TRRS cables, which is a great partner with many devices, such as smartphones, speakers, and so on.
Mono/Stereo Mode Available
The availability of mono and stereo modes in the 2.4GHz wireless microphone system allows users to choose the appropriate mode based on their specific recording needs and the nature of the audio content they are capturing. This flexibility ensures that the microphone system can adapt to a wide range of applications and deliver the desired audio output format.
